FQ-450 Precision High Speed Slitter trademark
Features:
FQ-450 type automatic cutting machine is fully automatic reel-standard printing presses, die-cutting machine reel supporting products, the machine is suitable for slitting narrow strip, with frequency control, automatic meter count, count the number of sheets, set the length of automatic parking, alarm, unwinding automatic correction by the photoelectric eye control, air shaft rewinding tension control, compact count the number of sheets made of imported electric eye, the whole structure, high speed slitting accurate, simple to operate, stable and so on.
The main technical parameters:
The maximum web width of 450mm
Roll largest diameter 400mm
The minimum slitting width 10mm
Cutting precision 0.2mm
External dimensions 1.2 × 1.2 × 1.4m
Slitting speed 70m / min
Machine weight 500kg
Note: Overall, the process is subject to change without notice.
|
